Roofing System
NOUVEL ZIP roofing system designed to provide the opportunity for freedom of expression, to meet the needs of the architect's creation.NOUVEL has developed innovative systems which use all the characteristic of material: long-lasting, malleable, flexible, aesthetic and prestigious.- Product Description
- Technical Datas
- Applications
-
NOUVEL ZIP Roofing System designed to provide the opportunity for freedom of expression, to meet the needs of the architect's creation.NOUVEL has developed innovative systems which use all the characteristic of material: long-lasting, malleable, flexible, aesthetic and prestigious.
NOUVEL offers a range of systems supplied with preformed finishing accessories produced specifically for covering facades in the public and residential sector, for both new construction and renovation.Suitable for all kinds of roofing and building shape more than 3 degrees (flat, curved, concave,outer concave, tapered, spherical and hyperbolic)
Commonly Used Panel Material:
Standard Roofing System
High efficient NOUVEL-ZIP standard roofing system is economical and high cost effective, which can satisfy most normal projects’ needs.
System Structure:
1.Lock Standing Seam System Panel
2.Mineral Wool Insulation
3.Pre-forming Liner
4.Purline
Big-span Roofing System
Together with super strong and big span profiled steel panel, NOUVEL-ZIP standard roof system can create a 4000mm span without any between support, which can save space and working time, create a pleasing simplicity. This system is suitable for huge public buildings with net frame and H-type steel structure.
System Structure:
1.Lock Standing Seam System Panel
2.Mineral Wool Insulation
3.Clip With Thermal Break Pad
4.Non-woven Tissue
5.Pre-forming Liner
Multi-layer Composition System
NOUVEL-ZIP standard roof system(multi-function) equipped with ventilated facade panels as decoration layer is a high efficient, waterproof, insulating, sound-absorbing and decorating system. This system is suitable for complicated architectural buildings with round shape, dome, or arc shape.
System Structure:
1.Decorative Panel
2.Lock Standing Seam System Panel
3.Waterproof Breathable Membrane
4.Mineral Wool Insulation
5.Damp Proof Membrane
6.Purline
7. Acoustic Wool
8.Non-woven Fabrics
9.Perforation Pre-forming Liner
Multi-function Roofing System
NOUVEL-ZIP standard system boast excellent water proofing property through adding a second layer of waterproof and sound-absorbing materials. The opposite-fixed perforated panels hides the roof structure, integrating with sound-absorption and ceiling decoration functions, which is suitable for stadium, exhibition hall, station, airport and other populated buildings of steel structure.
System Structure:
1.Lock Standing Seam System Panel
2.Waterproof Breathable Membrane
3.Mineral Wool Insulation
4.Steel mesh
5.Clip With Thermal Break Pad
6.Purline
7.Acoustic Slab
8.Vapor Barrier membrane
9.Preforation Pre-forming Liner
Product Benefits
1.Light weight, durability and economic efficiency
2.Excellent performance of wind pressure, after
lock will not pull off and deformed
3.Overallstructural waterproofing,drainage function
4.Field production, construction convenient, fast
5.Can be used for slope smaller roof (> 3 °)
6.No screw holes, corrosion performance increase
7.Excellent thermal insulation, fire resistance
8.Perfect suction dumb, noise performance
9.Green, 100% recycled
Applications:
Major airports, railway stations, stadiums, convention centers, museums and other public and rezidential buildings.
